    Fully Automatic Robotic Single Column Palletizer for Boxes Unloading

    Ask Lasest Price
    Price : Individual quotation according to different requirements
    Brand Name : Peiyu
    Model Number : customized
    Certification : CE,ISO9001:2008,High-tech enterprise
    Payment Terms : L/C,T/T
    Supply Ability : 300 pcs per month
    Delivery Time : 30-40 workdays
    • Product Details
    • Company Profile

    Fully Automatic Robotic Single Column Palletizer for Boxes Unloading



    Product Description

    The single-column palletizing machine is composed of an acceleration belt, a steering stacking roller, a case arrangement table, a column, a beam, a pallet divider and a roller conveyor, and it is suitable for stacking various packages such as carton, plastic case, shrink film package or other packaging pieces.
    The workflow, the machine is automatically stack the cartons on the pallet layer by layer according to the pre designed stack type. Under the combined action of single column lifting mechanical structure and pushing box structure stacking to a specified height and the cartons stack is passed through the roller conveyor line moved to the forklift and transported to the warehouse for storage. This kind of machine controlled by PLC and touch screen, realize high degree of automation, simple, easy to master, small floor space, high palletizing efficiency, low failure rate and convenient maintenance.

    Operating ModeStacking layer by layerConveyor Height750mm
    Capacity60 Cartons/minPallet Conveyor Height500mm
    Driven TypeElectricMaximum Load Per Layer200kg
    Pallet SizeStandard Pallet (as demanded)Maximum Load Per Pallet1500Kg
    Dimension9500*6000*3700mmApplicable ProductCarton,Plastic case,Shrink film packaging
    Palletizing Storage15 palletsTotal Power22KW
    Weight8000kgTransport PackageFilm Packing or Wooden Case
    Fully Automatic Robotic Single Column Palletizer for Boxes Unloading
